12.2inch Rugged Tablet PC High-Performance
The RT15 Rugged Tablet PC features Ubuntu/Linux support, MIL-STD-810G certification, and a 12.2-inch sunlight-readable display. Perfect for industrial and outdoor use.
- IntelCorei5-1235U/i7-1255U processor
- 12.2inchIPS Full HD screen with 10-point capacitive touch
- 2.4G+5.8GDualband WIFI 6
- IP65 WaterproofandDustproof, Anti-Static
RT15 Rugged Tablet PC | 12.2-Inch Industrial Tablet with Ubuntu & Linux Support
The RT15 Rugged Tablet PC is a high-performance industrial device designed for demanding environments. With its 12.2-inch sunlight-readable display, MIL-STD-810G certification, and Ubuntu/Linux compatibility, this rugged tablet PC is perfect for industrial automation, logistics, and outdoor fieldwork.
Key Features & Benefits
1. Industrial-Grade Durability
- MIL-STD-810G Certification: Survives 1.22m drops onto concrete and operates in -20°C to 60°C temperatures.
- IP65 Protection: Resists dust and water jets for use in factories or rainy conditions.
- Reinforced Frame: Aluminum alloy housing ensures resistance to impacts and vibrations.
2. High-Performance Display
- 12.2-inch IPS Screen: 1920×1200 resolution with 650nits brightness for clear visibility in direct sunlight.
- 10-Point Capacitive Touch: Responsive even with gloves, paired with scratch-resistant glass.
- Wide Viewing Angles: 178° visibility ensures consistent visuals from any position on-site.
3. Ubuntu & Linux Support
- Ubuntu/Linux Compatibility: Pre-installed Ubuntu or optional Linux distributions for custom workflows.
- Intel® Core™ i5/i7 Processors: 10nm 10-core CPU (up to 4.4GHz) for seamless multitasking.
- 16GB RAM + 128GB SSD: Expandable storage for data-heavy industrial applications.
4. Field-Ready Connectivity
- Dual-Band Wi-Fi 6: 2.4GHz/5.8GHz Wi-Fi for stable data transfer in crowded environments.
- 5G/4G LTE: Optional 5G module for ultra-fast connectivity in remote areas.
- Multi-GNSS Support: GPS + Glonass + BeiDou for ±3m accuracy in warehouses or fieldwork.
Technical Specifications
| Category | Specifications |
|---|---|
| Display | 12.2-inch IPS (1920×1200), 650nits, 10-point capacitive touch |
| OS | Ubuntu (Pre-installed), Optional Linux Distributions |
| Processor | Intel® Core™ i5-1235U / i7-1255U (10nm, 10-Core) |
| Memory | 16GB RAM (Expandable) |
| Storage | 128GB SSD (Expandable via TF Card) |
| Wireless | Wi-Fi 6, Bluetooth 5.1, Optional 5G/4G, GPS/Glonass/BeiDou |
| Ports | USB 3.1, USB-C, HDMI 2.1, SIM, TF Card, 12-pin Pogo Pin |
| Durability | IP65, MIL-STD-810G, 1.22m Drop Resistance |
Why Choose RT15?
Industry-Specific Applications
- Factory Automation: Control PLCs and monitor production lines with Ubuntu/Linux software.
- Logistics & Warehousing: Track inventory with 5G and multi-GNSS navigation.
- Outdoor Exploration: Sunlight-readable display and rugged design for fieldwork.
Competitive Edge
| Feature | RT15 Rugged Tablet PC | Industry Average |
|---|---|---|
| Brightness | 650nits | 300-500nits |
| OS Flexibility | Ubuntu + Linux Support | Windows Only |
| Processor | Intel® Core™ i5/i7 (10-Core) | Intel® Celeron (4-Core) |
FAQs
Q1: Can I install custom Linux distributions?
A: Yes, the RT15 supports Ubuntu and other Linux-based OS for tailored workflows.
Q2: Is the screen readable in direct sunlight?
A: Absolutely. The 650nits IPS display ensures clear visibility outdoors.
Q3: Does it support legacy industrial equipment?
A: With RS232, USB, and Ethernet ports, it seamlessly integrates with PLCs and sensors.
More:If you need a 10.1-inch rugged tablet with Windows OS, check out our 10-inch Windows Rugged Tablet for seamless integration with industrial software and enhanced portability.
| Model | RT15 |
| Performance Parameter | |
| CPU | Intel Core i5-1235U/i7-1255U |
| OS | Windows 11/10 |
| RAM | 16GB |
| Storage | 128GB |
| Basic Parameters | |
| LCD | 12.2 inch IPS 16:10,1920×1200,650nits |
| Touch Panel | 10 point G+G capacitive touch screen |
| Camera | Front 2.0MP Rear 8.0MP |
| I/O | USB 3.1 Type-A×1,USB Type-C×1 SIM Card ×1,TF Card x1 HDMI 2.1a Mini x1 12PIN Pogo Pin x1 Φ3.5mm standard earphone jack×1 Φ5.5mm DC jack x1 |
| Power | AC100V~240V,50Hz/60Hz,Output DC 19V/3.42A |
| NFC | Optional,13.56MHz, Card reading distance:4cm |
| Fingerprint | Standard |
| RTC Battery | 3V 210mAH |
| Dimension | 339.3x 230.3x26mm |
| Weight | Device unit1500g |
| Device Color | Black |
| Battery | |
| Capacity | 7.4V/700mAh |
| Type | Built-in Li-polymer battery |
| Battery | |
| Capacity | 7.4V/6300mAh |
| Type | Removable Li-polymer battery |
| Endurance | 4.5hrs(50%volume sounds,200 lumens brightness 1080P HD video display by default) |
| Network connections | |
| WIFI | WiFi6802.11a,b,d,e,g,h,i,k,n,r,u,V,w,ac,ax(2.4G+5.8G) |
| Bluetooth | BT5.1 Transmission distance:10m |
| 5G | 5G SA&NSA: LTE FDD:B1/B3/B5/B7/B8/B20 LTE-TDD:B40 WCDMA:B1/B5/B8 GSM:B3/B8 N1/N3/N5/N7/N8/N20/N28/N38/N40/ N41/N71/N77/N78/N79 |
| GNSS | Support GPS,Glonass,optional Beidou |
| Reliability | |
| Operate Temperature | -20 ℃~60 ℃ |
| Store Temperature | -30 ℃~70 ℃ |
| Humidity | 95%Non-Condensing |
| Rugged Feature | IP65 certified,MIL-STD-810G certified |
| Drop Height | 1.22m drop |
| Electrostatic Discharge | ±8kV contact discharge,±15kV air discharge |
| Extension modules (1 out of 4) | |
| Ethernet interface | RJ45(Standard,10/100/1000M)×1 |
| Serial port | DB9(RS232)×1 |
| USB2.0 | USB 2.0×1 |
| 2D | Optional,Optical resolution:5mil/ scan speed:50 times/s |
